MAX Trailer MAX100
Die Farbe des Fahrzeugs auf dem Foto kann abweichen.
- Chassis number 111271
- Reference MAX100-N-3BA-9.30-U
- Number of axles 3
- Condition New
- Year of manufacture 2026
- Colour Farbe wählbar
- Availability 06/2026
- Steering Type Friction
Die wichtigsten Unterlagen
Detailinformationen
Technical data
Weights
| Technical value 80 km/h | |
|---|---|
| King pin load | 18000 kg |
| Axle load | 31500 kg |
| Gross weight | 49500 kg |
| Tare weight +- 3% | 11452 kg |
| Payload | 38048 kg |
Dimensions
| Fifth wheel height loaded | 1200 mm |
| Gooseneck length | 3 800 mm |
| Turning circle reversing | 2 100 mm |
| Loading platform length | 9 300 mm |
| Extendable by | 3 700 mm |
| Wheelbase | 1 360 mm |
| Loading height at max. load | 860 mm |
| Total width | 2 540 mm |
| Suspension stroke | -55/ +145 mm |
Gooseneck
1 x Gooseneck
Gooseneck with rear chamfered by ca. 750 mm x 10°.
3 pairs of lashing rings (LC 5 000 daN).
Hardwood cover thickness 30 mm.
- 1 tool box INOX on the gooseneck ± 1 350 x 400 x 400 mm. (± 46 kg)
Loading deck
Loading platform
1 x Loading platform
Loading platform in extendable version behind the gooseneck with hydraulically lift- and lowerable loading area ca. 2 800 mm length, with chamfered beaver tail by about 1 000 mm x 8°.
6 pairs of lashing rings in the loading platform, hinged outwards (LC 5 000 daN).
2 pairs of lashing rings in the loading platform, hinged outwards (LC 10 000 daN).
1 pairs of lashing rings in the loading platform, hinged inwards at the front (LC 10 000 daN).
Cutouts in the border frame of the loading area for hooking in tension belts. (LC 2 000 daN).
Hardwood cover thickness 48 mm above of the axles chequer plate.
- Yellow reflective tape according to the EU regulation over the entire length, on the extension and at the rear.
-
Hardwood timber for the outriggers (± 312kg).
The maximum permissible point load on an area of 200 x 200 mm is 3.5 to. - 1st Lift axle on the front axle with control by TEBS-E depending on the current axle load (± 69kg)
- One removable, galvanised sliding bolster, ± 250 mm wide (± 127 kg).
- Reflective tape red/white for the extension of the loading platform.
- 1 LED flashing beacon, provided separately.
Ramps
Hydraulic loading ramps
1 x Steel double flip ramps
1 pair steel double flip ramps galvanized ca. 2 750 + 1 400 x 800 mm with ca. 48 mm hardwood cover.
Ramps hydraulically operated and hydraulic side shift.
Maximal charge for one pair: 40 000 kg
Accessories
1 x Accessories
- Manual and description on USB stick .
- Holder for one beacon light at the rear right and left of the trailer.
- Spiral cable for the the electric-hydraulic pump and/or electric winch (35 mm², 3.5 m length, max. 160 A) between the semi-trailer and the truck with socket (ANDERSON-ANDERSON).
- Delivery from a trailer to factory Lentzweiler.
